CNC MILLING MACHINE CM1270
| MODEL |
CM-1270 |
| Controller |
GSK980MDa |
| Table Size |
1270 x254 mm |
| Travel X, Y, Z |
720 x380 x125 mm |
| Driving system |
GSK Servo motor |
| Spindle power |
3 HP |
| Spindle Size |
R8 |
| Spindle speed |
16 set, 160-5440 rpm |
| Maximum Part Weight |
250kg |
| T-Slot |
16 x3 x63.5 mm |
| Up Down Table |
360 mm |
| Head Rotation Angle |
90 degree |
| Front Rotate Angle |
360 degree |
| Front and Rear Travel |
470mm |
| Spindle to table distance |
40-430mm |
| Spindle center to table |
140-610mm |
| Size |
1900x1690x2100mm |
| Weight |
1290 kg |
CNC MACHINE CENTER YM-SERIES
| Model |
YM-6035 |
YM-1165 |
YM-1870 |
| Controller |
GSK/ SIEMENS |
GSK/ SIEMENS |
GSK/ SIEMENS |
| X travel |
600 mm |
1,100 mm |
1,800 mm |
| Y travel |
350 mm |
650 mm |
700 mm |
| Z travel |
450 mm |
470 mm |
550 mm |
| Servo Motor/ Drive |
SERVO SYSTEM |
| Feed Rate |
0-10,000 mm/min |
| Precision |
0.001 mm |
| Table |
1,000x300 mm |
1,400x320 mm |
1,900x530 mm |
| Max Table Load |
400 kg |
700 kg |
600 kg |
| Spindle Speed |
200-6,000 (8,000) rpm |
| Spindle Power |
3.7/5.0 KW |
| Tool Type |
BT40 |
| Size |
2,2000x2,100x2,200 mm |
2,700x2,650x2,300 mm |
2400x4000x2450 mm |
| Weight |
2,300 kg |
3,300 kg |
4500 |
| Tool Change |
Options: 12 tool change |
|
|
